    10 Bricks Fly Ash Making Machine

    10 Bricks Fly Ash Making Machine
    10 Bricks Fly Ash Making Machine
    Send Inquiry
    Product Code : ABMH-8SP Ultra belt
    Price And Quantity
    • Minimum Order Quantity
    • 1
    • Unit of Measure
    • Unit/Units
    • Price
    • 00.00 INR
    Product Specifications
    • Material
    • Fly Ash
    • Computerized
    • Yes
    • Automatic
    • Yes
    • PLC Control
    • Yes
    • Method
    • Hydraulic Pressure
    • Vibration Type
    • Flat Vibration
    • Number of Bricks
    • 12 Per Cycle
    • Feature
    • High Durability, Low Weight
    Product Description

    We are affianced to manufacture, export and supply the finest quality 10 Bricks Fly Ash Brick Making Machine. The provided plant is assembled by our ingenious professionals using quality-assured components and cutting-edge techniques. The offered plant is ideal for the hassle free production of fly ash brick for construction applications. In addition to this, our valuable customers can avail this 10 Bricks Fly Ash Brick Making Machine from us in various technical specifications at the most negotiable prices.

    Key Features:

    • Optimum performance having hassle free functioning
    • Long service life
    • High productivity with unmatched automation process
    • Low maintenance cost with minimum wear and tear

    Hydraulic Motor  15 H.P. & 1440 R.P.M. Flange Mounted
    Conveyor System Width: 600mm. Length: 23 Feet. 3 H.P. Motor with 1:25 Gear Box. Polymer Conveyor Belt.
    System  Hydraulic Free Fill
    Dimension Height: 2700mm,  Width: 1400mm,  Length:3500mm.
    Weight of Main Body 5500 kg ( 5.5 Tons )
    Panel Control World`s #1 Schneider Make PLC Control with Production Memory and Fault Alarm.
    Guide Rod 50mm x 1100mm EN8 Grinded and Hard Chromed
    Guide Bush 1st Quality Cast Iron with Derifiline Bearings
    Free Fill Tank Capacity 60 Liters
    Cycle Time 14-15 Seconds Power Pack High Pressure & Low Pressure
    Power Pack TANDUM Double Twin Pump "Denison" make. Capacity 280 Bars.
    No: of Bricks per Cycle 10 nos. 230 x 110 x 75mm
    Hydraulic Oil System 68/45 liters.
    Brick Eject Drive Rubber Conveyor Belt: 4 plyx110mmx800x8000 fitted with Gear Box:1:4 ratio and 2 H.P. Motor.
    Max Pressure 250 BAR
    Main Pressing Plate Dimension 760x650x105 Single Solid Plate well machined with CNC
    Pan Mixer: 500 Kg Capacity

    20 H.P. Motor Foot type. 1440 RPM Frame Size: 160

    Gear Box: Vertical No:9. Ratio: 1:40.

    Carbon Tipped Blade Arms.

    • Equipped with Cutting Edge Technology
    • Superb Innovation Equipment
    • The Very Latest Technology at the highest level
    • Twin Power Turbo Pump
    • Lower Power Consumption
    • World`s Best PLC Control System
    • Double Cylinder Press Technology
    • Easy Changeable Conveyor Belt
    • High Efficiency Heat Exchanger

    Trade Information
    • Supply Ability
    • 7 Per Month
    • Delivery Time
    • 20 Days
    • Sample Available
    • Yes
    • Sample Policy
    • Contact us for information regarding our sample policy
    • Main Domestic Market
    • All India
    • Certifications
